Input | 230Vac@50Hz |
Input Cable | 14AWG U.S.SPT-2/ EU-H03W AUST/NZ-H03WV |
Output
|
13.8V 10A for Lead-Acid batteries
14.4V 9A for LiF3PO4 batteries 12V 10A for DC Adapter |
Max Voltage
|
14.5V Lead-Acid (Pb) Battery Charging
14.9V AGM Battery Charging 14.4V LiFePO4 Battery Charging |
Min. Starting Voltage | 2.0V (the charger can’t charge battery under 2.0V) |
Output Cable | #14AWG insulated cable |
Overcharge Protection | Yes |
Short Circuit Protection | Yes |
Spark Proof | Yes |
Reverse Polarity Protection | Yes |
Cooling | Natural |
Operating Temperature | -10~50 degree |
Waterproof | IP64 |
Battery Capacity
|
Charging and maintenance all 30-300Ah
Lead-Acid Batteries Charging 9-108Ah LiFePO4 batteries |
Dimensions (mm) | 205(l) x 99(w) x 57(d) |
Clamp Cable Length | 23.6 inch |
Ring Terminal Cable Length | 23.6 inch |
Cigarette Cable Length | 23.6 inch |
WARRANTY
5 Years
FEATURES
• Smart, light and portable
• Multiple safety protections
• Chargers all Lead-Acid and Lithium Batteries
• Charging and maintenance all 30-300Ah Lead-Acid batteries
• Charging 9-108Ah LiFePO4 batteries
• Detects sulfation and acid stratifications
• Extends battery life
• LCD Display
