Ultra thin frame folding solar panel.
Portable suitcase style solar panel, a magnet handle instead of traditional lock and light stands make this foldable panel only half of the weight of the averaging suitcase style panel. The unit can be easily used in 3 steps: open it, lift up the stands and plug the cable to battery.
FEATURES
• The use of magnet handle simplifies the process to use it
• The weight is only half that of traditional solar panel suit case
• Better protection comparing to other light products
• Flexible cover to better protect the panel
• Durable carry/storage bag included
Maximum Power (PMAX) | 2000W |
Open Circuit Voltage (VOC) | 23.4 |
Voltage at PMAX (VMP) | 19.8 |
Short Circuit Current (ISC) | 10.71 |
Current at PMAX (IMP) | 10.10 |
Cells Efficiency (%) | 21.80% |
The Maximum System Voltage | 60VDC(IEC) |
Power Temperature Coefficient | -0.43%/°C |
Voltage Temperature Coefficient | -0.34%/°C |
Current Power Tolerance | 0.05%/°C |
Output Power Tolerance | ±3% |
Operating Temperature | -10 -60°C |
Solar Cell Brand | A grade solar cells |
No, of Cells & Connections | 36(4×9) |
Dimensions Unfolded (mm) | 1370x800x25mm |
Dimensions Folded (mm) | 800x685x50mm |
Weight | 9.5kg |
Waterproof Junction Box | IP65/IP67 |
Warranty | 2 Years & service life 10 years |
